Intersil ISL6209 Datasheet

The ISL6209 is a high frequency, dual MOSFET driver, optimized to drive two N-Channel power MOSFETs in a synchronous-rectified buck converter topology in mobile computing applications. This driver, combined with an Intersil Multi-Phase Buck PWM controller, such as ISL6216, ISL6244, and ISL6247, forms a complete single-stage core-voltage regulator solution for advanced mobile microprocessors. The ISL6209 features 4A typical sink current for the lower gate driver. The 4A typical sink current is capable of holding the lower MOSFET gate during the PHASE node rising edge to prevent the shoot-through power loss caused by the high dv/dt of the PHASE node. The operation voltage matches the 30V breakdown voltage of the MOSFETs commonly used in mobile computer power supplies. The ISL6209 also features a three-state PWM input that, working together with most of Intersil multiphase PWM controllers, will prevent a negative transient on the output voltage when the output is being shut down. This feature eliminates the Schottky diode, that is usually seen in a microprocessor power system for protecting the microprocessor, from reversed-output-voltage damage. The ISL6209 has the capacity to efficiently switch power MOSFETs at frequencies up to 2MHz. Each driver is capable of driving a 3000pF load with a 8ns propagation delay and less than a 10ns transition time. This product implements bootstrapping on the upper gate.


Intersil ISL6209 Datasheet - cover page
Brand
Intersil
Category
Other Electronics
Document type
Datasheet
Language
English
Pages
10
File format
PDF
File size
997 KB
Published
28 March, 2012
Updated
30 September, 2023
MD5 checksum
1BAF8B6BABFF9B48C2DF39398AB9EA2F

About this manual

The ISL6209 dual MOSFET driver is designed for synchronous‑rectified buck converters in mobile computing applications. It provides a typical 4 A sink current for the lower gate and operates up to 30 V, supporting switching frequencies as high as 2 MHz.

Key features include a three‑state PWM input, programmable dead‑time (5 ns‑50 ns), internal bootstrap Schottky diode, and shoot‑through protection with gate‑threshold monitoring. The device is offered in 8‑lead QFN (L8.3×3 mm) and SOIC‑8 packages.

What's inside

  • Features
  • Pinouts
  • Typical Application
  • Absolute Maximum Ratings
  • Electrical Specifications
  • Functional Pin Description
  • Operation
  • Three‑State PWM Input
  • Shoot‑Through Protection
  • Layout Considerations

Specifications

Typical sink current (lower gate)4 A
Operating voltage0.3 V to 30 V
Maximum switching frequency2 MHz
Programmable dead‑time range5 ns to 50 ns
Package options8‑lead QFN (L8.3×3 mm) or SOIC‑8

Frequently asked questions

What is the typical sink current capability of the ISL6209?

The driver can sink up to 4 A typical current on the lower gate.

What is the maximum switching frequency supported?

The ISL6209 can switch MOSFETs at frequencies up to 2 MHz.

How is dead‑time programmed on the ISL6209?

Dead‑time is set by adding a resistor from the DELAY pin to ground, giving a range of 5 ns to 50 ns.

What is the operating voltage range for the device?

The driver operates from about 0.3 V up to 30 V.

Download PDF (997 KB)
