ISL6612A and ISL6613A are high frequency MOSFET drivers specifically designed to drive upper and lower power N-Channel MOSFETs in a synchronous rectified buck converter topology.
The ISL6612A and ISL6613A are high‑frequency MOSFET drivers designed for synchronous rectified buck converters. They provide dual gate drives, adaptive zero shoot‑through protection, and a three‑state PWM input to improve efficiency and prevent shoot‑through.
The document includes features, ordering information, pinouts, electrical specifications, thermal data, and application examples for use with Intel® and AMD® microprocessor core regulators and high‑current DC‑DC converters.
| Supply Voltage (VCC) range | 0 V to 15 V |
|---|---|
| PVCC operating range | 5 V to 12 V |
| Maximum switching frequency | up to 2 MHz |
| Sinking current capability | 3 A |
| Ambient temperature range | -40 °C to 85 °C |
| Maximum junction temperature | 125 °C |
The drivers support a switching frequency of up to 2 MHz.
They operate from –40 °C to 85 °C ambient temperature.
The drivers provide a sinking current capability of 3 A.
