The ISL6295 is a low‑voltage fuel‑gauge IC that measures, stores, and reports critical rechargeable‑battery parameters such as charge/discharge current, voltage, and temperature. It integrates a 16‑bit sigma‑delta A/D converter, on‑chip voltage regulator, non‑volatile EEPROM, and an SMBus/I²C‑compatible 2‑wire communication interface.
Typical applications include notebook PCs, PDAs, and other handheld devices that use single‑cell Li‑ion/Li‑Polymer packs. The device is supplied in an 8‑lead TSSOP package and operates from –20 °C to +85 °C with very low supply currents in various power‑saving modes.
| Operating Supply Voltage (VP Pin) | -0.5 V to 10 V |
|---|---|
| Supply Current – Run Mode | 85 pA typical |
| Supply Current – Sample Mode | 45 pA typical |
| EEPROM Storage | 256 bytes |
| Package | 8‑lead TSSOP |
| Operating Temperature Range | -20 °C to +85 °C |
It uses an industry‑standard SMBus/I²C compatible 2‑wire interface for host communication.
The device includes 256 bytes of non‑volatile EEPROM for storing factory‑programmed and user‑defined parameters.
Typical supply current in run mode is 85 pA.
The ISL6295 is offered in an 8‑lead TSSOP package.
