BBT3420 is a quad 2.488-3.1875Gbps/channel transceiver that supports full rate and half rate, with a maximum data rate of 12.75Gbps.
The BBT3420 is a quad 8‑bit/10‑bit parallel‑to‑serial and serial‑to‑parallel transceiver designed for high‑bandwidth interconnections such as line cards, backplanes, or optical modules. It offers four independent channels with configurable data rates, pre‑emphasis, and built‑in self‑test features.
The device is supplied in a 289‑pin 19 mm × 19 mm HSBGA package, operates from a single 1.8 V supply, and consumes about 250 mW per channel. It supports both XAUI and XGMII interfaces and includes extensive MDIO‑controlled configuration options.
| Number of channels | 4 |
|---|---|
| Data rate per channel | 2.488‑3.1875 Gbps (up to 12.75 Gbps full‑duplex) |
| Maximum full‑duplex throughput | 12.75 Gbps |
| Typical power consumption per channel | 250 mW |
| Supply voltage | 1.8 V |
| I/O tolerance | 3.3 V tolerant I/O |
| Package | 289‑pin 19 mm × 19 mm HSBGA |
| Encoding | 8‑bit/10‑bit parallel‑to‑serial and serial‑to‑parallel |
The BBT3420 consumes about 250 mW per channel under typical conditions.
Each channel supports 2.488‑3.1875 Gbps, and the device can reach up to 12.75 Gbps full‑duplex.
The device provides four independent transmitter and receiver channels.
It is packaged in a 289‑pin 19 mm × 19 mm HSBGA.
