This document describes the features and characteristics of the AD7813 8-/10-bit sampling ADC from Analog Devices, including operating voltage range, conversion time, interface type, power consumption, etc.
The AD7813 is a microprocessor‑compatible analog‑to‑digital converter offering 8‑/10‑bit resolution, a 2.3 µs conversion time, and automatic power‑down for low‑power operation. It operates from a single 2.7 V to 5.5 V supply and is available in DIP, SOIC and TSSOP packages.
The device features an 8‑bit parallel interface, on‑chip track‑and‑hold, and dynamic specifications such as SNR and THD for DSP applications. Power consumption is 10.5 mW in normal mode and as low as 34.6 µW at 1 kSPS in power‑down mode.
| Supply Voltage Range | 2.7 V to 5.5 V |
|---|---|
| Resolution | 10 Bits |
| Maximum Throughput | 400 kSPS |
| Conversion Time | 2.3 µs max |
| Normal Operation Power Consumption | 10.5 mW |
| Power‑Down Consumption @ 1 kSPS | 34.6 µW |
It operates from a single supply of 2.7 V to 5.5 V.
Typical power consumption in normal operation is 10.5 mW.
The conversion time is specified as 2.3 µs maximum.
The device provides 10‑bit resolution (8‑bit parallel interface with 2‑bit LSB read).
