ADA4410-6 is a comprehensive integrated filtering solution that is carefully designed to give designers flexibility and performance with excellent video specifications
The ADA4410-6 provides a comprehensive filtering solution for a wide range of video standards, including RGB, YPbPr, YUV, SD, and composite video. It offers selectable sixth‑order filter cutoffs (9 MHz, 18 MHz, 36 MHz), gain selection (×2 or ×4), and DC offset adjustment, making it suitable for set‑top boxes, DVD players, and HDTVs.
The datasheet includes detailed specifications, pin configurations, PCB layout recommendations, and ordering information for the 32‑lead LFCSP package, along with thermal and absolute‑maximum ratings for reliable design integration.
| Supply Voltage Range | +4.5 V to +5 V |
|---|---|
| Input Bias Current | 6.6 pA |
| Typical Output Swing | 4.5 V p‑p on single 5 V supply |
| Quiescent Current (enabled) | 82‑88 mA |
It operates from +4.5 V to +5 V on a single supply, and also supports dual‑supply operation for applications that need negative voltage swing.
Gain is selectable via a logic pin, offering either ×2 or ×4 gain settings.
The input bias current is very low, specified at 6.6 pA.
The device provides a typical output swing of 4.5 V peak‑to‑peak when powered from a single 5 V supply.
