This is an application and design manual for RF products, featuring new developments and products in SiGeC RF transistor and RF MMIC technologies, including BFU725F, CATV 1-GHz modules, WiMAX transceivers, and satellite LNB. The manual also introduces new BAW filters.
The NXP RF Manual 10th Edition is an application and design guide covering a wide range of RF products, including transistors, MMICs, diodes, filters, and modules. It offers detailed application notes, product portfolios, design‑in tools such as S‑parameters and SPICE models, and cross‑reference tables for discontinued parts.
The manual also includes packaging information, marking codes, and contact details for NXP distributors worldwide, making it a comprehensive reference for engineers designing RF solutions.
| Document order number | 9397 750 16105 |
|---|---|
| Date of release | September 2007 |
| Printed in | the Netherlands |
The document order number is 9397 750 16105.
It was released in September 2007.
The manual is available at www.nxp.com/rfmanual.
