HEF4060B is a 14-stage ripple-carry binary counter/divider and oscillator. It contains three oscillator terminals (RS, RTC and CTC), ten buffered outputs (O3 to O9 and O11 to O13) and an overriding asynchronous master reset input (MR).
The HEF4060B is a 14‑stage ripple‑carry binary counter/divider and oscillator featuring three oscillator terminals (RS, Rte, Cre), ten buffered outputs (O0‑O8 and O10‑O13) and an asynchronous master reset input (MR). The device can operate with either an RC or crystal oscillator circuit, or accept an external clock signal on the RS pin.
The datasheet includes pinning diagrams, package options, electrical characteristics, timing component limitations, and test set‑up information, allowing designers to integrate the IC into a wide range of timing and frequency‑division applications.
| Stage count | 14‑stage ripple‑carry binary counter/divider |
|---|---|
| Oscillator terminals | RS, Rte, Cre |
| Master reset input | Asynchronous MR (active HIGH) |
The HEF4060B can be configured as an RC oscillator, a crystal oscillator, or accept an external clock signal applied to the RS pin.
