The BGY916 is a three-stage UHF amplifier module from Philips, packaged in SOT365A. The nominal supply voltage is 26V and the output power is 16W with an RF drive power of 25mW.
The Philips BGY916 is a three‑stage UHF amplifier module in a SOT365A package, designed for base‑station transmitting equipment operating in the 920‑960 MHz band. It integrates a silicon planar NPN transistor and two MOS‑FET dies on a metallized ceramic substrate with built‑in matching and bias circuitry.
The document provides detailed electrical characteristics, limiting values, package dimensions, component list and mounting recommendations, including thermal‑compound usage and bolt torque specifications for reliable heat‑sink attachment.
| Nominal supply voltage | 26 V |
|---|---|
| Maximum supply voltage | 28 V |
| Output power (into 50 Ω) | 16 W |
| Frequency range | 920‑960 MHz |
| Power gain | 28‑32 dB |
| Efficiency | 35‑40 % |
| Storage temperature range | -30 °C to +100 °C |
| Operating temperature range | -10 °C to +90 °C |
The nominal supply voltage is 26 V.
It operates from 920 MHz to 960 MHz.
The module can deliver up to 16 W into a 50 Ω load.
Mounting bolts should be tightened to a maximum of 0.4 – 0.6 Nm.
