ASUS P4P800S SE Motherboard User Manual

P4P800S SE 2 is a motherboard product from ASUS.

Brand: ASUS
Category: Board
Document type: User Manual
Language: Chinese
Pages: 78
File format: PDF
File size: 5.2 MB
Published: 22 March, 2012
Updated: 30 September, 2023
Model: P4P800S
MD5 checksum: 8E8122299D010B206922589B2464F2B4
PDF: ASUS P4P800S SE Motherboard User Manual PDF

About this manual

This user manual covers everything needed to install and configure the ASUS P4P800S SE motherboard, including hardware installation steps, jumper settings, and BIOS configuration. It also explains the special features of the board such as the Instant Music Lite function.

Safety precautions, power‑up procedures, and software support information are included, along with contact details for ASUS technical support worldwide. This manual is written in Chinese.

What's inside

Product Introduction
Hardware Installation
BIOS Configuration
Software Support
Safety Information
Jumper and Icon Explanation
Contact Information

Specifications

BIOS Feature	CrashFree BIOS 2
ACPI 2.0 Support	No
Instant Music Lite Power Requirement	+5VSR ≥ 2 A

Frequently asked questions

How do I enable the Instant Music Lite feature?

Enter the BIOS Advanced Menu, select Instant Music, and set the option to Enabled.

What safety steps should be taken before installing the motherboard?

Disconnect the power adapter and unplug the power cord from the outlet before handling any components.

What power supply is required for Instant Music Lite?

The power supply must provide at least 2 A on the +5VSR rail.
