P4P800-X motherboard specification
This manual provides all the information needed to install and configure the ASUS P4P800-X motherboard, including safety precautions, hardware specifications, BIOS configuration, and software support. It also explains how to update the BIOS and install drivers for the various onboard components.
The document is organized into chapters covering product introduction, safety notices, BIOS settings, jumper configurations, connector descriptions, driver installation, and online upgrade procedures. Helpful symbols and warnings are explained to ensure safe and correct installation. This manual is written in Chinese.
| Supported CPU | Pentium 4 / Xeon |
|---|---|
| Northbridge Chipset | Intel 845 |
| Southbridge Chipset | Intel 82801 |
| Memory Type | DDR 200 DDR memory (unbuffered, non‑ECC) |
| Audio Codec | AD1888 |
| Network Controller | Realtek RTL8100C 10/100 Mbps Ethernet |
The power adapter must be unplugged from the wall outlet before removing the computer power.
BIOS updates can be downloaded from the ASUS website using the ASUS Live Update utility.
Jumper settings are shown with icons: a filled circle for a set jumper and an empty circle for a free jumper.
The ASUS PC Probe program provides diagnostics for CPU temperature, fan speed, and system voltages.
