LANPARTY 875P-T Motherboard User Manual

This is the HP System Board User's Manual, which introduces the characteristics and usage of the motherboard.

Brand: LanParty
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 48
File format: PDF
File size: 1.7 MB
Published: 22 March, 2012
Updated: 30 September, 2023
MD5 checksum: 894CADECCF6291B86FF2BE74128F65EB
PDF: LANPARTY 875P-T Motherboard User Manual PDF

About this manual

This manual covers the quick‑setup procedure for the LANPARTY 875P‑T system board, including safety notices, power‑supply requirements and installation steps. Detailed diagrams show the board layout, rear‑panel I/O ports, and connector pin‑outs.

The document also lists the technical specifications of the motherboard, such as the supported processor, chipset, memory configuration, BIOS features and expansion slots, and provides guidance for BIOS configuration and troubleshooting. This manual is written in Chinese.

What's inside

Quick Setup Guide
System Board Layout
Jumpers
Rear Panel I/O Ports
I/O Connectors
Features and Specifications
BIOS Configuration
Troubleshooting

Specifications

Processor	Intel® Pentium® 4 Prescott
CPU Socket	LGA 775
Chipset	Intel® 875P (Intel® 82875P MCH)

Frequently asked questions

What CPU socket does the LANPARTY 875P‑T motherboard use?

It uses an LGA 775 (LAN Grid Array) socket.

What is the minimum 5VSB current required for the power supply?

The 5VSB source must support at least 720 mA.
