This is a user manual for Rev. A+ System Board
This manual covers the hardware layout, supported processors, memory configurations, and expansion slots of the LANParty 865PE system board. It includes detailed BIOS setup steps, power‑management options, and safety warnings for installation and servicing.
Additional sections provide troubleshooting checklists, connector pin‑outs, and guidance for configuring peripheral devices such as hard drives, printers, and serial ports.
| Chipset | Intel® 865PE |
|---|---|
| CPU Socket | Socket 478 |
| Supported Processors | Intel® Pentium® 4 (800 MHz/533 MHz bus), Pentium® 4 Northwood, Intel® Celeron® Northwood |
| Memory Slots | Four 84‑pin DDR DIMM sockets |
| Maximum Memory | Up to 4 GB system memory |
| Memory Interface | Dual‑channel 128‑bit wide |
| AGP Support | AGP 3.0 (4x and 8x) and AGP 2.0 (1x and 4x) |
| PCI Slots | 5 PCI slots |
It uses a Socket 478 for installing supported Pentium 4 and Celeron processors.
The board provides four 84‑pin DDR DIMM sockets.
The motherboard supports AGP 3.0 (4× and 8×) and AGP 2.0 (1× and 4×).
Up to 4 GB of system memory can be installed.
