This document is the product guide of Intel® Desktop Board DG965WH, which introduces the features and characteristics of the product.
This guide covers the main features of the Intel DG965WH desktop board, including supported processors, memory configurations, chipset details, graphics, audio, USB, SATA, and LAN capabilities. It also contains detailed instructions for installing components, updating the BIOS, configuring RAID, and using the Intel Quick Resume Technology driver.
Regulatory compliance sections describe FCC, Canadian, EU, and other international certifications, along with safety and EMC requirements. The document is intended for technically qualified personnel who install and maintain the board in personal computers and similar environments.
| Form Factor | ATX (320.04 mm x 243.84 mm) |
|---|---|
| Processor Support | Intel processor in LGA775 package |
| Chipset | Intel G965 Express Chipset |
| Graphics | Intel Graphics Media Accelerator X3000 |
| Audio | 8‑channel (7.1) onboard, Intel High Definition Audio |
| USB Ports | Up to 10 USB 2.0 ports |
| SATA | Six SATA channels (3.0 Gb/s) |
| LAN | Gigabit (10/100/1000 Mb/s) Ethernet |
| BIOS Flash Memory | 8 Mbit symmetrical flash |
It provides up to ten USB 2.0 ports, with six on the back panel and four routed to internal headers.
It includes a Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel® 82566DC controller.
