This document is the product guide for the Intel® Desktop Board DQ45CB, which provides information about the performance and features of the product. The board complies with FCC and Canadian Department of Communications standards and has good electromagnetic compatibility. The document also mentions potential interference issues and their solutions. Additionally, it emphasizes that users are not allowed to modify or alter the device without explicit permission.
This product guide describes the Intel DQ45CB desktop motherboard, covering its functional overview, hardware layout, supported processors, memory configurations, chipset features, graphics, I/O options, power management and compliance information. It is intended for qualified technicians and system designers who need detailed installation and configuration instructions.
The document includes step‑by‑step procedures for installing the CPU, memory modules, expansion cards, and cables, as well as instructions for updating the BIOS, configuring Intel Matrix Storage RAID, and enabling Rapid Recover Technology. Safety, regulatory and certification details are also provided. This manual is written in Chinese.
| Form factor | microATX (243.84 mm x 243.84 mm) |
|---|---|
| Processor socket | LGA775 |
| Chipset | Intel Q45 Express |
| Integrated graphics | Intel Graphics Media Accelerator 4500 (GMA 4500) |
| USB ports | 12 USB 2.0 ports |
| LAN controller | Intel 82567LM Gigabit Ethernet |
It supports Intel processors that use the LGA775 socket.
The board provides up to twelve USB 2.0 ports.
It is a microATX board measuring 243.84 mm × 243.84 mm.
