The Intel® Desktop Board DG45ID Product Guide introduces the DG45ID desktop board features and characteristics, including installation, usage, and troubleshooting.
This guide details the features and specifications of the Intel DG45ID desktop motherboard, including its microATX form factor, LGA775 processor socket, up to 8 GB DDR2 memory, and Intel G45 Express chipset. It also covers supported interfaces such as HDMI/DVI‑I dual display, up to 12 USB 2.0 ports, SATA ports with RAID, and a gigabit LAN controller.
Installation procedures, BIOS update methods, RAID configuration, Rapid Recover Technology setup, error codes, and compliance with FCC, CE, ENERGY STAR and other standards are described to assist qualified technicians in proper system integration and maintenance. This manual is written in Chinese.
| Form factor | microATX (243.84 mm × 243.84 mm) |
|---|---|
| Processor socket | LGA775 |
| Maximum memory | 8 GB DDR2 SDRAM (800/667 MHz) |
| Chipset | Intel G45 Express (GMCH + ICH10R) |
| USB ports | Up to 12 USB 2.0 ports (6 rear, 6 internal) |
| LAN controller | Intel 82567LF gigabit Ethernet |
The DG45ID supports Intel processors using the LGA775 socket.
The board supports up to twelve USB 2.0 ports—six on the back panel and six via internal connectors.
Yes, it supports SATA RAID through Intel Matrix Storage Technology and can be used with Intel Rapid Recover Technology.
