The Maxim DS8023 is a low‑power smart‑card interface IC supporting ISO 7816, GSM 11‑11 and EMV 2000 standards. It operates from 1.8 V, 3 V or SV supplies and offers ultra‑low standby current.
The document provides absolute maximum ratings, recommended DC operating conditions, detailed pin descriptions, clock source options, timing parameters and layout recommendations for reliable board design. This manual is written in Chinese.
| Maximum Junction Temperature | +125 °C |
|---|---|
| Maximum Power Dissipation (‑40 °C to +85 °C) | 700 mW |
| Storage Temperature Range | -55 °C to +150 °C |
| Standby (Stop‑Mode) Current | 10 nA |
| Vpp Voltage Range | 2.7 V to 6.0 V |
The DS8023 can operate up to a junction temperature of +125 °C.
In stop mode the DS8023 draws about 10 nA of current.
Vpp can be supplied between 2.7 V and 6.0 V relative to ground.
