This is a Z-300S-1 multi-function audio and video device with CD and VCD playback function
This manual provides safety precautions, control descriptions, and connection instructions for the Z-30S/300S video‑CD/CD player. It includes detailed guidance on handling discs, cleaning the unit, and troubleshooting common issues.
Additional sections cover remote‑control usage, playback functions (video, audio, game, karaoke), system specifications, and recommended servicing procedures. The document emphasizes that the player is for home use only and must not be used in commercial settings.
| Power consumption | 8.5 |
|---|---|
| Weight | 3.7 kg |
| Dimensions | 420 mm (W) × 334 mm (D) × 111 mm (H) |
| Operating temperature | +6 °C to 45 °C |
| Video output level | 1 Vp‑p (75 Ω load) |
| Audio output level (channel 1) | 2 Vrms (1 kHz, 0 dB) |
| Audio output level (channel 2) | 0.5 Vrms (1 kHz, 0 dB) |
| Audio frequency response | 20 Hz – 20 kHz |
| Signal‑to‑noise ratio | 85 dB |
| Total harmonic distortion | 0.496 % at 1 kHz, 0 dB |
No, the manual states the unit is designed for home use only and must not be used in business applications.
