This manual explains how to install and operate the TCL LCD52M06 liquid‑crystal television. It covers safety warnings, connection diagrams, remote‑control functions, picture‑mode settings and quick‑access features such as picture‑in‑picture and aspect‑ratio selection.
Technical specifications, recommended cleaning methods, and a troubleshooting guide are included to help users resolve common issues like no picture, no sound, or interference. The document also lists the contents of the package and provides contact information for customer support. This manual is written in Chinese.
| Screen diagonal | 133 cm |
|---|---|
| Rated power consumption | 260 W |
| Audio output power | 8 W + 8 W |
| Working voltage | 220 V ~ 50 Hz |
| Weight (with stand) | ≈ 39 kg |
| Dimensions (with stand) | 1276 mm × 907 mm × 344 mm |
| Operating temperature range | 5 °C ~ 35 °C |
| Operating humidity range | 20 % ~ 80 % |
| Storage temperature range | -15 °C ~ 45 °C |
| Preset channel memory | 200 channels (1‑200) |
The TV can store up to 200 preset channels (1‑200).
No. Use a dry soft cloth or a liquid‑crystal‑specific cleaning agent; do not apply water or other chemicals.
No. Avoid touching the screen directly with fingers to prevent damage and oil residue.
