This manual provides the safety guidelines, installation steps, and operating instructions for the Lehua LCD37M15 LCD TV. It covers the main features, connection ports, and multimedia functions, helping users set up the television for both TV and computer display use.
The document also includes detailed technical specifications, quick‑operation shortcuts, and a fault‑analysis section to assist with common issues such as no picture, no sound, or remote‑control problems. This manual is written in Chinese.
| Model | LCD37M15 |
|---|---|
| Audio Output Power | 8W + 8W |
| Working Voltage | 220 V ~ 50 Hz |
| Rated Power Consumption | 190 W |
| Screen Diagonal Size | 9%4 cm |
| Main Unit Dimensions (W×H×D) | 940 mm × 672 mm × 120 mm |
| Dimensions with Base (W×H×D) | 940 mm × 715 mm × 300 mm |
| Weight (with Base) | ≈ 20.8 kg |
| Base Weight | ≈ 4.3 kg |
| Operating Temperature | 5 °C ~ 35 °C |
| Storage Temperature | -15 °C ~ 48 °C |
| Storage Humidity | 10 % ~ 90 % |
| Supported TV Standards | PAL, DK, NTSC, SECAM |
