This manual covers important safety warnings, proper handling, and installation guidelines for the ROWA LE19C18 LED‑backlit LCD television. It explains how to connect power, video sources (VGA, HDMI, CVBS, S‑Video) and use the built‑in speakers and remote control.
Technical specifications such as native resolution, screen size, power consumption, input voltage and supported video modes are listed, along with a troubleshooting section for common issues like no picture or sound. This manual is written in Chinese.
| Maximum Resolution | 1920 x 1080 |
|---|---|
| Native Resolution | 1360 x 768 @60Hz |
| Pixel Pitch | 0.3 mm x 0.3 mm |
| Screen Size (W×H) | 409.80 mm × 230.40 mm |
| Input Voltage | 220 V ~ 50 Hz |
| Standby Power Consumption | 1 W |
| Operating Power Consumption | 35 W |
| Audio Output Power | 2 W + 2 W |
| Supported TV Standards | PAL + NTSC |
| Weight (unpacked) | 4.0 kg |
The recommended VGA mode is 1360 × 768 @ 60 Hz.
In standby the TV consumes about 1 W.
The TV requires a 220 V, 50 Hz AC power source.
Installed dimensions are 528 mm × 415 mm × 100 mm.
