This manual introduces the TCL LCD19M08 liquid crystal television, covering safety warnings, usage environment, and cleaning instructions. It explains the TV's features such as high‑resolution display, built‑in speakers, multiple input interfaces, and power‑saving functions.
Detailed sections describe how to connect the antenna, DVD, computer, and other AV sources, install the remote‑control batteries, and perform basic troubleshooting. Technical specifications and accessory lists are also provided. This manual is written in Chinese.
| Maximum resolution | 1440x900 |
|---|---|
| Input voltage | 100‑250V~ 60/50Hz |
| Unpacked weight | ≈6.0 kg |
| Color depth | 16.7 M colors |
| Screen surface treatment | Anti‑glare |
| Standby power consumption | ≈2W |
| Recommended operating mode | 1440 × 900 @ 60 Hz |
Remove the battery cover and insert two AAA (7 V, 1.5 V) cells, making sure the polarity matches the “+” and “‑” markings inside the battery compartment.
Connect one end of the antenna cable with an IEC plug to the TV’s antenna input, and the other end to the outdoor antenna or cable‑TV socket.
Connect the DVD player’s Y, Pb/Cb, and Pr/Cr output terminals to the TV’s corresponding Y, Pb/Cb, and Pr/Cr input terminals.
In standby mode the TV consumes about 2 W of power.
