This manual provides a detailed introduction to the functions and features of the VS-132 Video Splitter, as well as how to install and use the product.
The VS-132 is an analog video splitter that duplicates a single video source to two outputs and can extend transmission up to 65 m (210 ft). It supports XGA, VGA, SVGA and multisync monitors and can be cascaded to provide up to eight video signals.
The manual covers package contents, hardware requirements, front‑panel description, step‑by‑step installation, cascading instructions, and a full specification table, including video resolution, power consumption, operating temperature, and physical dimensions.
| Video Resolution | 1920 x 1440 @80 Hz |
|---|---|
| Maximum Cable Distance | Up to 65 m (210 ft) |
| Power Consumption | AC 9 V, 120 mA (max) |
| Operating Temperature | 0–50 °C |
| Storage Temperature | -20–60 °C |
| Weight | 0.19 kg |
| Dimensions (L × W × H) | 10.40 × 9.80 × 2.40 cm |
| Housing Material | Metal |
| LED Indicators | 1 Signal Indicator, 1 Power Indicator |
The VS-132 provides one video input to two video outputs and can be cascaded to three levels, allowing up to eight video signals in total.
The splitter can transmit video signals up to 65 m (210 ft) without loss of quality.
