This manual covers safety warnings, warranty information, and detailed installation guidelines for the RE‑Q1180A microwave, including required clearances, grounding, and electrical load requirements. It also lists the appliance specifications such as voltage, power consumption, dimensions, and timer settings.
The guide explains how to operate the microwave, describing automatic cooking modes, manual power and time settings, defrost functions, and proper container usage. Maintenance, cleaning, and after‑sales service procedures are also provided to help keep the oven in good working condition. This manual is written in Chinese.
| Rated Voltage | 110V, 60Hz |
|---|---|
| Rated Power Consumption | 1450W |
| Rated High‑Stable Wave Output | 800W (CNS) |
| External Dimensions | 550 mm × 400 mm × 305 mm |
| Internal Dimensions | 367 mm × 372 mm × 210 mm |
| Weight | 22 kg |
| Timer Capacity | 99 min 99 sec |
The microwave must be connected to a 110 V, 60 Hz power supply.
Its rated power consumption is 1450 W.
Leave at least 5 cm on each side and at least 10 cm above and behind the unit.
