This manual covers the installation of the FT-D371S fax machine, including required accessories, paper loading, and safety precautions. It describes the control panel layout, function keys, and how to configure date, time, device name, and telephone numbers.
Detailed sections explain how to load originals, select scan modes, dial numbers (speed‑dial, direct, and redial), and send or receive faxes. Advanced features such as automatic fax/telephone switching, hands‑free operation, and volume control are covered, followed by maintenance procedures, cleaning tips, and a troubleshooting guide. This manual is written in Chinese.
| Maximum Paper Size | 216 mm × 297 mm |
|---|---|
| Power Consumption (Maximum) | 115 W |
| Power Consumption (Standby) | 5 W |
| Input Voltage | 110 V 60 Hz |
| Dimensions (W × D × H) | 360 mm × 240 mm × 85 mm |
| Weight | 2.05 kg |
| Operating Temperature | 5 °C – 35 °C |
| Supported Original Thickness (single sheet) | 0.08 mm – 0.13 mm |
| Supported Original Thickness (multiple sheets) | 0.08 mm – 0.11 mm |
| Transmission Speed Options | 9600, 7200, 4800, 2400 bps |
Enter the month, day, year, hour and minute in order using the keypad; fill leading zeros if needed, then press the confirm key to complete the setting.
Press the edit key, then input the new telephone number (up to 20 digits) and confirm; the number will be saved for future use.
Open the paper roll cover, use a soft cloth lightly dampened with alcohol to wipe the print head, then dry with a clean dry cloth.
