This document is a user manual for the Vision Sensor with built-in LCD monitor Smart Sensor ZFX-C10/C15. The manual includes information about application considerations, basic operations, setting the measurement conditions, functions used during operation, additional functions, parallel interface, and appendices.
This manual introduces the Omron ZFX-C10/C15 vision sensor, describing its basic operations, measurement settings, and optional functions. It also outlines the parallel interface and includes appendices for further reference.
Extensive safety and usage precautions are covered, including installation environment, power‑supply requirements, wiring guidelines, and handling instructions to ensure reliable performance and compliance with warranty terms.
| Power supply voltage | 24 VDC ±10% |
|---|
The voltage and AC power supply must be within the rated range of 24 VDC ±10%.
Ensure the product is turned OFF before connecting or disconnecting any cables.
No, do not peel off or cover the ventilation film, as it protects the device.
