This manual provides information regarding operations and input/output format that are required for communication between ZFC-V controllers and external devices using the OMRON proprietary communication protocol, Compoway/F
This manual provides the communication command reference for the OMRON ZFV‑C intelligence sensor. It is intended for engineers and technicians who need to integrate the sensor with OMRON controllers using the proprietary CompoWay/F protocol.
The document covers how communication works, how to set communication specifications, command and response formats, examples of abnormal ends, and detailed command listings for reading and writing parameter areas, controller information, and operation instructions. It also includes revision history and contact information for OMRON support.
| Connection interfaces | USB cable or RS‑232C cable |
|---|
You can use either a USB cable or an RS‑232C cable; for USB you must install the appropriate driver first.
The start byte is the STX code, which is 02Hex.
