Barksdale electronic temperature sensor, can set zero point and range, has a compact structure, robust 304 stainless steel casing, IP65 or IP67 protection rating, can be used for ship building, measuring range of 0-100 °C, application range of hydraulics and pneumatics, machinery and equipment manufacturing, mobile hydraulics, test and inspection equipment, marine applications.
The Barksdale UTA 3 is an electronic temperature‑measurement transmitter housed in a compact stainless‑steel enclosure (IP65/IP67). It is designed for hydraulic, pneumatic, machine‑building, mobile‑hydraulic, marine and other industrial applications.
Key specifications include a wide temperature range from –30 °C to 4150 °C, an accuracy class of 0.5 % of full‑scale, Pt100 sensor (Class B), 600 bar pressure rating, and selectable 4‑20 mA or 0‑10 V output signals. The device operates from an 8‑30 V DC supply and weighs only 130 g. This manual is written in German.
| Measurement range | -30 °C … 4150 °C |
|---|---|
| Accuracy class | 0.5 % of full‑scale |
| Sensor type | Pt100 (Class B), DIN IEC 751 |
| Housing material | Stainless steel 1.4571 |
| Sealing material | Viton, EPDM |
| Maximum pressure | 600 bar |
| Protection class | IP65 (plug) / IP67 (cable) |
| Power supply | 8 … 30 V DC (unregulated) |
| Output signals | 4‑20 mA (2‑wire) or 0‑10 V (3‑wire) |
| Dimensions (without coupling socket) | 24 mm × 86 mm |
| Weight | 130 g |
The UTA 3 can measure from –30 °C up to 4150 °C.
It has an accuracy class of 0.5 % of full‑scale.
The transmitter provides 4‑20 mA (2‑wire) and 0‑10 V (3‑wire) outputs.
It is rated IP65 for the plug and IP67 for the cable.
