This manual outlines important safety precautions, including electrical warnings, fire‑hazard warnings, and proper handling of the machine. It also details installation requirements such as level adjustment, placement on a flat surface, and correct connection of power and water supplies.
The guide explains how to operate the washing machine, describes the function of each control panel element, and lists technical specifications such as power supply, dimensions, capacity, water consumption, spin speed, and noise levels for the four model variants. This manual is written in Chinese.
| Power supply | 220V~, 50Hz |
|---|---|
| Dimensions (L×W×H) | 600 mm × 440 mm × 850 mm |
| Weight | 60 kg (WD‑N1017/T1017), 65 kg (WD‑N8017/T8017) |
| Maximum power | 2100 W (WD‑N1017/T1017), 2200 W (WD‑N8017/T8017) |
| Washing capacity | 5.2 kg (WD‑N1017/T1017), 7 kg (WD‑N8017/T8017) |
| Water consumption per cycle | 60 L (5 kg models), 72 L (7 kg models) |
| Standard water pressure | 30 kPa – 1000 kPa |
| Washing noise | 59 dB(A) |
| Spin noise | 70 dB(A) |
The supply pressure should be between 30 kPa and 1000 kPa.
Place the machine on a flat, stable surface, adjust the level so the tilt does not exceed 1°, and keep the distance to the power outlet within 1.5 m.
WD‑N1017 and T1017 hold up to 5.2 kg, while WD‑N8017 and T8017 hold up to 7 kg.
Use a dedicated 220 V, 10 A three‑core socket, ensure proper grounding, do not use damaged power cords, and unplug the machine before cleaning.
