This manual covers essential safety precautions, proper installation on a level floor, and detailed operation instructions for the LG XQB45-368SN and XQB60-78SF front‑loading washing machines. It explains how to set water levels, select wash programs, and maintain the appliance safely.
Technical specifications, component descriptions, drain‑pipe installation, and warranty information are also included, helping users understand the machine’s capabilities and service requirements. This manual is written in Chinese.
| Voltage / Frequency | 220 V / 50 Hz |
|---|---|
| Washing Capacity | 6.0 kg |
| Water Inlet Pressure | 0.03‑1 MPa |
| Dimensions (W×D×H) | 525 mm × 530 mm × 844 mm |
| Weight | 30.0 kg |
| Washing Noise | 57 dB(A) |
| Spin Noise | 67 dB(A) |
Place the machine on a flat, stable floor, keep at least 15 cm clearance around it, and adjust the leveling feet until the unit is level.
Read all safety warnings, avoid water contact with electrical parts, keep the appliance away from fire, do not overload, and ensure the power supply matches the rated voltage.
