This manual explains how to install, connect, and operate the Alpine PXA-H701 multimedia manager. It covers basic controls, Ai‑NET networking, automatic time correction (AUTO TCR), and detailed EQ settings.
Safety warnings, recommended operating conditions, and troubleshooting steps are included to help users avoid damage and ensure reliable performance in vehicle audio systems. This manual is written in Japanese.
| EQ bands per channel | 31 bands |
|---|---|
| Frequency range | 10 Hz – 24 kHz |
| Control unit weight | 159 g (5 oz) |
| Power supply voltage | 12 V |
The device should be used in temperatures between +6 °C (+140 °F) and –10 °C (14 °F).
No. The manual states the unit must not be installed in high‑humidity or wet locations.
It provides three analog inputs and three digital inputs.
