This document is an instruction manual for the Panasonic DMC-TS1GK camera, describing its features and characteristics.
This manual begins with safety precautions, including warnings about fire, electric shock, and proper handling of the battery and charger. It explains the camera’s waterproof, dust‑proof and shock‑resistant ratings, and gives detailed instructions for battery charging, replacement, and environmental limits.
The later sections cover camera operation such as shooting modes, menu navigation, playback functions, memory‑card handling, and connection interfaces. Technical specifications, accessory lists, and regulatory information are also provided. This manual is written in Chinese.
| Dimensions | 98.3 mm (W) × 63.1 mm (H) × 23.0 mm (D) |
|---|---|
| Weight (without battery) | 162.5 g |
| Weight (with battery and card) | 183.8 g |
| Operating temperature | 0 °C to 40 °C |
| Waterproof rating | IPX8 (up to 3 m depth for 60 min) |
| Dust‑proof rating | IP5X |
| Battery voltage / capacity | 3.6 V / 940 mAh |
| Battery charger input | 110 V–240 V, 50/60 Hz, 0.2 A |
| Battery charger output | 4.2 V / 0.65 A |
| Internal memory size | ≈40 MB |
| Maximum still images per charge | ≈340 images |
| Full charge time | ≈130 minutes |
It meets the IEC 60529 IPX8 rating, allowing it to be used at a depth of up to 3 m for 60 minutes.
A full charge takes about 130 minutes.
Approximately 340 images can be captured on a full charge.
The camera operates between 0 °C and 40 °C.
