8DH10 switchgear is a factory-assembled, type-tested, three-pole, metal-enclosed, metal-clad single-busbar switchgear for in-door installation. The rated voltage is 24 kV, short circuit current 630 A, and busbar current 1250 A.
The Siemens 8DH10 is a factory‑assembled, type‑tested, three‑pole, metal‑enclosed, gas‑insulated medium‑voltage switchgear designed for indoor installation. It offers modular design, maintenance‑free operation, and can be extended without on‑site gas work.
The catalog provides technical data, product range overview, panel dimensions, installation guidelines, shipping information and compliance with IEC 62271‑200 standards. It lists typical applications such as substations, high‑rise buildings, wind power stations and industrial plants.
| Rated voltage | 24 kV |
|---|---|
| Feeder current rating | 630 A |
| Busbar current rating | 1250 A |
| Insulating gas | SF₆ |
| Maintenance concept | Maintenance‑free |
The 8DH10 is rated for up to 24 kV.
The feeder current rating is 630 A.
The switchgear uses SF₆ as the insulating gas.
Yes, it features a maintenance‑free concept.
