This document is the Siemens SIMOSEC switchgear user manual. It provides detailed information about the product's features, characteristics, application scenarios, and technical parameters.
This catalog describes the Siemens SIMOSEC series of air‑insulated, extendable medium‑voltage switchgear rated up to 24 kV. It includes typical applications such as substations, industrial plants, and public utilities, and outlines the modular design that allows free combination and extension of panels.
The document contains technical data (voltage, current, pressure, temperature), installation recommendations, shipping dimensions, and a full product range overview covering ring‑main, transformer, cable, circuit‑breaker, metering, and bus sectionalizer panels.
