The document provides information about various models of Siemens industrial steam turbines, including their technical parameters such as inlet pressure, inlet temperature, and rotational speed. These steam turbines have a power range from 2 to 250 MW and are suitable for different industrial applications.
The Siemens SST-100 is a single‑cylinder industrial steam turbine designed for flexible installation and reliable operation. It delivers up to 8.5 MW of power and can be used to drive generators, compressors, pumps or fans in various industrial processes.
Key technical data include a 65 bar inlet pressure, 480 °C inlet temperature, 7500 rpm speed and compact dimensions (8 m × 3.7 m × 3.4 m). The turbine features a quick‑install design, radial exhaust, integrated oil system and customizable steam flow paths to meet specific customer requirements. This manual is written in Chinese.
| Output power | 8.5 MW |
|---|---|
| Inlet pressure | 65 bar |
| Inlet temperature | 480 °C |
| Speed | 7500 rpm |
| Back‑pressure exhaust | 10 bar |
| Condensing exhaust | 1 bar |
| Exhaust area | 0.22 m² |
| Typical dimensions | Length 8 m × Width 3.7 m × Height 3.4 m |
The SST‑100 can deliver up to 8.5 MW of power.
Its typical size is 8 m long, 3.7 m wide and 3.4 m high.
It is used for driving generators, compressors, pumps or fans in various industrial processes.
