Siemens provides prefabricated pipeline compressor units that integrate a standard Siemens gas turbine (STC7TY) with a Siemens turbine‑compressor. The units are offered in three models (SPCP‑100, SPCP‑200, SPCP‑400) to match SGT‑100, SGT‑200 or SGT‑400 gas turbines, delivering high efficiency and pressure ratios up to 2.0.
The leaflet lists advantages such as single‑source supply, competitive pricing, short lead times, and includes technical documents like drawings, P&ID’s and critical speed reports. Detailed specifications for each model cover power, rated speed, maximum pressure and nozzle size. This manual is written in Chinese.
| SPCP‑100 Power | 4.92 MW |
|---|---|
| SPCP‑100 Rated Speed | 13,000 rpm |
| SPCP‑100 Max Pressure | 110 barg |
| SPCP‑100 Nozzle Size | 2 inch |
| SPCP‑200 Power | 7.68 MW |
| SPCP‑200 Rated Speed | 10,950 rpm |
| SPCP‑200 Max Pressure | 110 barg |
| SPCP‑200 Nozzle Size | 4 inch |
| SPCP‑400 Power | 13.4 MW |
| SPCP‑400 Rated Speed | 9,500 rpm |
| SPCP‑400 Nozzle Size | 30 inch |
The units are offered for three turbine models: SGT‑100, SGT‑200 and SGT‑400.
The package includes compressor drawings, basic data, P&ID’s and reports on torsional and lateral critical speeds.
The SPCP‑200 can reach a maximum pressure of 110 barg.
