The ASRock M3A785GM-LE motherboard is a high-performance desktop motherboard. This manual provides detailed information on the motherboard's features and usage, as well as installation instructions and troubleshooting tips.
This manual introduces the ASRock M3A785GM-LE motherboard, lists the package contents, and details the technical specifications such as CPU support, chipset, memory limits, and integrated graphics.
It then guides users through hardware installation, BIOS configuration, and software support, including the use of the supplied Support CD and driver utilities.
| Form Factor | Micro ATX (9.6‑in x 7.8‑in) |
|---|---|
| CPU Socket | Socket AM3 |
| Chipset | Northbridge AMD 785G, Southbridge AMD SB710 |
| Maximum Memory | 8 GB |
| SATA Connectors | 6 × Serial ATAII 3.0 Gb/s (RAID supported) |
| LAN | Gigabit LAN (Realtek RTL8111DL) |
It supports Socket AM3 processors, including AMD Phenom II and Athlon II series.
The board provides six Serial ATAII 3.0 Gb/s connectors with RAID, NCQ, AHCI, and Hot Plug support.
The motherboard can handle up to 8 GB of DDR3 memory across its two DIMM slots.
