The PEOPLE RDJR6 series is a fully digital motor soft starter that provides smooth start, soft stop and fault protection for a wide range of industrial motors. It uses a micro‑processor controller and offers both local panel operation and external control via terminals.
The document covers the device’s main features, installation dimensions, control terminal assignments, parameter settings, basic connection principles, and a detailed list of error codes with their meanings, helping users configure and maintain the starter safely. This manual is written in Chinese.
| Rated power (kW) for RDJR6‑5.5 | 5.5 kW |
|---|---|
| Rated power (kW) for RDJR6‑75 | 75 kW |
| Height (mm) for RDJR6‑5.5 | 11 mm |
The soft start function limits the starting current to 0‑20 mA, providing a smooth start and reducing mechanical stress.
Yes, external control is possible via the listed control terminals such as KA1, KA2, and common terminals.
