ASRock P45TS-R / P45TS motherboard is based on Intel P45 chipset, supporting LGA 775 interface Intel Core 2, Core 2 Extreme, Core 2 Quad processors, up to 4GB DDR2 memory, integrated Intel 82579LM Gigabit Ethernet, supports multiple storage device interfaces.
This document provides the installation instructions for the ASRock P45TS-R / P45TS motherboard. It includes details on the layout of memory slots and other key connectors.
The guide shows the arrangement of DDRII and DDR3 slots, helping users correctly install compatible memory modules before completing the system build.
| Memory slots (DDRII) | DDRII_A1, DDRII_A2, DDRII_B1, DDRII_B2 |
|---|---|
| Memory slots (DDR3) | DDR3_A1, DDR3_B1 |
The motherboard is manufactured by ASRock.
