The document describes the features and characteristics of a High-Definition Multimedia Interface (HDMI) product.
This manual provides safety precautions, proper grounding, power‑supply requirements and installation guidelines for the Chimei DTL-637S200 LCD monitor. It explains how to connect the supplied AC power cord, use a three‑core extension cord, and keep ventilation openings clear.
The guide also describes the on‑screen display (OSD) controls, supported input ports (HDMI, YGA, S‑Video, AV, PC audio), picture settings such as contrast, brightness and response time, and a troubleshooting section for common issues like no power, abnormal colors, or image distortion. This manual is written in Chinese.
| Contrast Ratio | 1500:1 (standard) |
|---|---|
| Brightness | 500 cd/m² |
| Response Time | 8 ms (Tr), 5 ms (Tf) |
| Maximum Resolution | 1366 × 768 |
| Power Supply | 100‑240 V AC |
The monitor must be connected to a grounded AC outlet using a three‑core extension cord; if unsure, a qualified electrician should verify the grounding.
