Instruction manual for using the NV-GS328GK digital camera
This manual begins with safety precautions and a list of supplied accessories, then describes how to install the lens cap, attach the hand strap, and connect power. Detailed sections cover battery charging, power‑on procedures, and how to switch between tape and memory‑card recording modes.
Further chapters explain menu navigation, language selection, recording functions (zoom, focus, night‑vision, etc.), playback options, and troubleshooting tips. The final part lists the camera’s technical specifications, including recording format, sensor details, and power requirements. This manual is written in Japanese.
| Recording format | Mini DV (consumer digital video SD format) |
|---|---|
| Tape size | 6.35 mm digital video tape |
| Video system | CCIR 625 lines, 50 Hz PAL |
| Audio recording | PCM 16‑bit 48 kHz, 2‑channel |
| Lens | 10:1 optical zoom, 3.0‑30.0 mm focal length, F1.8‑F2.8 |
| LCD monitor | 2.7‑inch |
| Weight (without battery) | ≈ 450 g |
| Power consumption (recording) | 5.2 W |
Connect the AC adapter to a wall outlet, then attach the DC input cable to the adapter and the camera; the charging indicator will light while charging and turn off when complete.
Make sure the battery is fully charged, check the battery protection circuit, connect the AC adapter for 5‑10 seconds, and verify that either the LCD monitor or the viewfinder is turned on.
Press the MENU button, select LANGUAGE, and choose the desired language from the list.
