This document is the user manual for the intelligent pressure sensor/switch SPS300A/B, which describes the necessary precautions for correct and safe use of the product, as well as maintenance and troubleshooting instructions.
This manual covers all necessary information for safely installing, wiring, and operating the Azbil SPS300A/B pressure sensor/switch. It includes safety requirements, detailed wiring diagrams for wall‑mount and panel‑mount configurations, and step‑by‑step operating procedures.
Additional sections describe troubleshooting, maintenance, part replacement, disposal, and the technical specifications of the device, ensuring users can correctly integrate the sensor into their control systems. This manual is written in Chinese.
| Supply Voltage (AC100/120V) | Type F, 100 mA, 250 V |
|---|---|
| Supply Voltage (AC200/240V) | Type F, 50 mA, 250 V |
| Power Consumption | ≤ 7 W |
| Over‑voltage Category | Category I (IEC60364‑4‑443, IEC60664‑1) |
| Pollution Degree | 2 |
The device consumes 7 W or less.
It can be powered from AC100/120 V (Type F, 100 mA, 250 V) or AC200/240 V (Type F, 50 mA, 250 V).
