CS5260BD/BDP is an ultra-compact and lightweight integrated camera. The main features are DC12V drive, ultra-compact and lightweight camera body, One-Push white balance, and relatively accurate white balance under complex light
The CS5260BD/CS5260BDP is a compact, integrated CCD color camera that operates on a DC12V supply. It includes built‑in white‑balance adjustment and supports both NTSC and PAL video standards.
Key specifications include an Interline CCD sensor with 811 × 508 effective pixels, a 1/2‑inch optical image size, 230 mA power consumption at 12 V, and a weight of 95 g. The camera offers a VIDEO OUT pin, multiple adjustment signals, and a one‑push auto/hold white‑balance function. This manual is written in Japanese.
| Sensor type | Interline CCD |
|---|---|
| Effective pixels | 811 × 508 |
| Optical image size | 1/2 inch |
| Power consumption | 230 mA @ 12 V DC |
| Weight | 95 g |
The camera operates on DC12V with a tolerance of ±10%.
It draws about 230 mA when powered from a 12 V DC source.
The camera weighs approximately 95 g.
It provides 811 horizontal by 508 vertical effective pixels.
