S1200 series full Gigabit ordinary switch is a Gigabit Ethernet switch launched by TG-NET. It provides 24 10/100/1000M adaptive ports, with a maximum transmission speed of 2000M per port, which is an ideal choice for improving the network speed in the local area network.
This manual introduces the S1200 series gigabit Ethernet switches, covering their purpose, specifications, and basic operation. It includes a product overview, performance features, and detailed descriptions of the front‑panel and rear‑panel indicators.
Installation guidance covers unpacking, desktop or rack mounting, power connection, and initial startup procedures. The document also explains LED status indicators, port configurations, and technical data such as supported standards and environmental limits. This manual is written in Chinese.
| Backplane bandwidth | 48 Gbps |
|---|---|
| Supported IEEE standards | 802.3, 802.3u, 802.3ab, 802.3z |
| Power input | 160‑265 V AC, 50‑60 Hz |
| Maximum power consumption | ≈30 W |
| Dimensions (rack‑mount) | 440 mm × 285 mm × 44.5 mm |
| Operating temperature | 0 °C to 40 °C |
| Storage temperature | -40 °C to 70 °C |
It operates on an AC power source ranging from 160 V to 265 V at 50‑60 Hz.
