This document is about the installation manual for Asus motherboard. The manual provides instructions on quick assembly steps, BIOS management and updates, troubleshooting common issues, and maintenance tips. Asus motherboard is a product of Asus Computer Company and unauthorized copying or reproduction is prohibited.
This guide provides step‑by‑step instructions for installing CPUs, attaching heat‑sinks, connecting power and data cables, and mounting the motherboard in a chassis. It also includes safety precautions and recommended handling of components.
Additional sections cover BIOS update methods, troubleshooting common issues, and maintenance tips such as cleaning and storage recommendations. This manual is written in Chinese.
| CPU socket type | Socket 775 (Socket T) |
|---|
Place the CPU into the Socket 775, align the gold triangle, lower the retention lever, and secure the CPU as described in the installation steps.
You can use AFUDOS, AwargBIOS Flash, or the ASUS online BIOS Updater to flash a new BIOS version.
Cover the board to prevent dust, use a dry brush or compressed air, and store it with desiccant packs to avoid moisture.
