The ASUS RS100-E5/PI2 server is an entry-level enterprise server that supports multiple processor series, providing data security and network reliability, and is suitable for various application requirements.
The RS100-E5/PI2 is a 1U mini rackmount server that combines Intel Xeon 3000 series processors, dual Gigabit Ethernet, and optional RAID 0/1 storage in a space‑saving chassis. It includes ASUS's own remote management card (ASMB3) and a PCI‑E x16 slot for additional expansion.
Designed for small‑ to medium‑size businesses, the server offers low power consumption, quiet operation (30 dB noise), and a range of operating system support including Windows Server 2003, Red Hat Enterprise Linux, and SuSE Linux. Certifications such as UL, CE, FCC and C‑TICK ensure compliance with global safety and EMC standards. This manual is written in Chinese.
| Form factor | 1U mini rackmount server |
|---|---|
| Memory type | DDR2 667/800 Unbuffered ECC |
| Memory capacity | 512 MB, 1 GB, 2 GB |
| Storage | 2 SATA drives, RAID 0/1 support |
| Network interface | Broadcom BCM5721 PCI‑E Gigabit NIC with dual ports, load balancing and failover |
| Power supply | 220 W single power supply |
| Dimensions | 380 mm × 430 mm × 43.4 mm (without packaging) |
| Operating temperature | 10 °C ~ 35 °C |
| Noise level | 30 dB |
The server provides two SATA drive bays and supports RAID 0 and RAID 1 configurations.
It includes a Broadcom BCM5721 PCI‑E Gigabit NIC with dual ports that support load balancing and failover.
The unit uses a single 220 W power supply.
