The ASUS RS100-X5/PI2 server is a 1U ultra-short mini server powered by a dual-core Intel Xeon 3000 processor. It features two gigabit server-grade network cards, support for disk arrays (RAID0, 1), and other characteristics. This server offers a multi-core processor solution, allowing users to choose from the Intel Xeon 3000 series or Intel Core2 Duo processors for powerful data processing performance and secure and reliable file data information. Additionally, the ASUS RS100-X5/PI2 server supports various unique management technologies and software tools, reducing maintenance costs and providing a flexible and high-performance solution.
The RS100‑X5/PI2 is a 1U mini‑tower server that supports dual‑core Intel Xeon 3000 series, Intel Core2 Duo, or Intel Conroe‑L 400 series processors. It includes two Gigabit Marvel 8056 network adapters, RAID‑0/1 capable SATA‑II storage, a PCI‑E x16 slot, and up to 2 GB DDR2 memory.
Key features include Smart Fan II temperature control, web‑based management tools (ASWM 2.0), multiple OS support (Windows Server, RedHat, SuSE), and certifications for UL, CE, FCC, and other regional standards. The compact chassis measures 38.0 cm × 43.0 cm × 4.34 cm (1U). This manual is written in Chinese.
| Processor | Dual‑core Intel Xeon 3000 series (65 W) / Intel Core2 Duo / Intel Conroe‑L 400 series |
|---|---|
| Chipset | Intel 945GC + ICH7 |
| Memory Capacity | Up to 2 GB DDR2 667/533 un‑buffered, non‑ECC |
| Memory Slots | 2 × DIMM |
| Storage | 2 × SATA‑II drive bays, RAID 0/1 support |
| Power Supply | 180 W single‑rail (document also mentions optional 300 W unit) |
| Network | 2 × Marvel 8056 Gigabit NICs |
| Expansion Slots | 1 × PCI‑E x16 (full‑height/half‑length) |
| Dimensions (without packaging) | 38.0 cm × 43.0 cm × 4.34 cm (1U) |
| Operating Temperature (operating) | 10 °C ~ 35 °C |
It supports dual‑core Intel Xeon 3000 series, Intel Core2 Duo, and Intel Conroe‑L 400 series processors.
The server includes two Marvel 8056 Gigabit network adapters.
Supported OSes include Windows Server 2000/2003 (32/64‑bit), RedHat Enterprise Linux 3.0/4.0 (32/64‑bit), and SuSE Linux Enterprise Server 9.0.
The circuit design keeps power draw below 1 A, and the unit uses a 180 W power supply.
