This document introduces how to use ProTool configuration software to create projects whose processes are visualized in Windows®.
This manual provides safety information for Siemens SIMATIC HMI graphics display units, including hazard symbols such as Danger, Warning, Caution and Notice, and specifies that only qualified personnel may perform setup and operation. It also outlines the proper use of the equipment, emphasizing compliance with applicable standards and Siemens‑approved components.
The document describes the configuration process using ProTool software families (ProTool, ProTool Lite, ProTool Pro) for creating projects on various HMI panels and operator units (e.g., OP 27, TP 170A, MP 270). It includes basic configuration steps, methods for extending configurations with simple elements, and examples of screen design for touch panels and text‑display units. This manual is written in Chinese.
Configuration is performed with the ProTool family of software: ProTool, ProTool Lite, and ProTool Pro.
