ZY_WRBCS-2W series power module is a wide voltage input isolated regulated single output power module. It has high conversion efficiency, good high and low temperature characteristics, strong capacitance load capacity, and features such as controllable output. It is suitable for computer peripherals, industrial control systems, data communication equipment, etc.
This handbook describes the ZY_WRBCS-2W isolation regulator series, highlighting its high isolation voltage (1500 V DC), wide input voltage range, and selectable output voltages. It includes information on protection features such as short‑circuit protection and fire‑retardant (UL94‑V0) packaging.
The document contains detailed electrical specifications, performance curves, pinout data, and mechanical dimensions for PCB mounting. It also provides a disclaimer regarding liability and usage restrictions. This manual is written in Chinese.
| Isolation Voltage | 1500 V DC |
|---|---|
| Bandwidth | 20 MHz |
| Operating Temperature Range | -40 °C to +85 °C |
| Typical Accuracy | 1 % |
The regulator provides a 1500 V DC isolation voltage.
The device operates from –40 °C to +85 °C.
