TA Series User Manual, this manual introduces the features of TA Series products, including product specifications, system packaging instructions, disassembly of the chassis, installation of hard drives, etc.
This manual covers the TA Series motherboard produced by Gigabyte. It includes detailed specifications such as dimensions, supported storage devices, and connector pinouts.
The document also provides installation instructions, describing the layout of memory slots, IDE and PCMCIA interfaces, power connectors, and supported CD‑ROM types, helping users set up the board correctly. This manual is written in Chinese.
| Dimensions (W × H × D) | 70 mm × 236 mm × 213 mm |
|---|---|
| Supported CD‑ROM | 24X Slim CD‑ROM or DVD‑ROM |
| PCMCIA Slot | Present |
| Hard Drive Interface | 2.5" Slim HDD |
The board measures 70 mm wide, 236 mm high, and 213 mm deep.
It supports a 24X Slim CD‑ROM or DVD‑ROM.
Yes, a PCMCIA slot is included on the board.
